Advance Mark 7 IZT-2S24-D T5 Dimming Ballast

Special Price $119.35 Regular Price $159.13

SKU

BD1-IZT-2S24-D

Advance Mark 7 IZT-2S24-D for (2) F24T5/HO, (2) FT24W/2G11. Input for 120/277v

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Advance Mark 7 IZT-2S24-D Dimming Ballast

Mark 7 0-10v electronic controllable ballasts for linear T5HO lamps combine the long life and energy efficiency of fluorescent technology with the controllability and full-rangedimming of incandescent systems. And they’re easy to install because they require no additional wiring.

Minimum starting temperature of 50F

Provides Lamp EOL Protection Circuit for all T5, T5/HO and CFL lamps

Lamp Current Crest Factor of 1.7

Contains auto restart circuitry in order to restart lamps without resetting power

Minimum ballast factor of 1.00 at maximum light output and 0.05 at minimum light output for primary lamp application

More Information

More Information
Order Code	IZT2S24D35M
Input Volts	120-277V
Brand	Advance Mark 7 0-10V
Mfg #	IZT2S24D35M
# of Lamps	2 Lamps
Product Data Sheet	IZT-2S24-D
Certifications	Class P, CSA, FCC Part 18 (Class A), Outdoor Type 1, Sound Rated: A, UL
Equivalents	NA
Start Method	Programmed Start
Starting Temperature	50ºF, 10ºC
Lamps	(2) F24T5/HO, (2) FT24W/2G11
Dimensions	16.7" x 1.18" x 1"
Case Size	ea
Warranty	5 Year Advance Warranty
UPC	781087134627
